Aliplast Panorama Folding Door System

Aliplast Panorama Folding Door System

The Aliplast Panorama Folding Door System is an aluminum folding system for balcony, terrace and winter-garden openings, with public and commercial buildings also listed among its applications. Its linked leaves fold together to open a glazed passage, so it offers a different movement pattern from a sliding patio door. The Panorama family includes the DV and DV i+ versions; the Europrestige listing identifies Panorama without naming one of those versions. Aliplast lists shared family parameters of 74.5 mm frame depth, 74.5 mm leaf depth, 16–50 mm infill thickness and maximum leaf weight of 100 kg. These values describe system options and limits rather than the dimensions or weight of a finished door. The folding layout affects both the closed appearance and the space required beside the opening. The folded stack therefore belongs in the same clearance review as the open passage. When reviewing a plan, look at the likely width of each leaf, where the folded stack will sit, and how much of the span must remain clear for everyday access. The manufacturer lists inward- and outward-opening arrangements, with groupings such as 2+1, 3+2 and 3+3. Leaf count and opening direction are design decisions to match the opening and its surroundings. The family parameters help frame early layout discussions: the 16–50 mm infill span gives a glazing or panel thickness range, while the 100 kg maximum leaf weight is a system limit. The chosen panel dimensions and arrangement still need to fit the particular opening and movement pattern.

Layouts for balconies, terraces and wide openings

Panorama offers standard and flat threshold solutions. The flat option is described with a brush seal and an airtight threshold design, while a standard threshold provides another system approach to the floor junction. The choice should be coordinated with the floor build-up and the path people use through the opening; it also belongs with the selected leaf arrangement rather than being decided from an illustration alone. Aliplast lists hinges with a lower carriage and pull handle, along with low-profile handle choices. Those system options let a specification address how the leaves are supported and how the moving panels are gripped, while the precise combination depends on the configured door. The Panorama family has DV and DV i+ variants, and the published Uf values differ between them; this listing does not identify which version applies, so no variant-specific Uf is assigned here. The table records shared family dimensions, limits and available layout choices. Treat them as manufacturer system references when comparing an opening plan, and use the selected version and assembly specification for a particular design decision.

Specifications
