Aliplast Superial Aluminum Window System

Aliplast Superial Aluminum Window System

The Aliplast Superial Aluminum Window System is the base SP aluminum and polyamide profile platform for fixed and opening window designs. Aliplast lists a 75 mm frame depth, an 84 mm sash depth, and a glazing capacity of 14–61 mm, giving the window designer a clear profile envelope for selecting the glass build and sash arrangement. The profile system supports single- and double-sash windows that open inward or outward. That range makes the base Superial window adaptable to different room layouts: a fixed portion can maintain a broad glazed area, while selected opening sashes provide ventilation where it is needed. Rectangular or rounded glazing beads alter the visual edge around the glass, allowing the frame detail to feel more linear or softened. Traditional or concealed drainage choices affect how water paths are handled at the profile, with concealed drainage keeping the exterior detailing visually restrained. Aliplast also lists profiles suited to different hardware, including hidden hinges, so the hardware approach can support either a visible fitting detail or a cleaner sash outline. These documented system choices make Superial SP a practical basis for matching window function and appearance to an architectural opening.

Superial SP Profile and Window Design

For the base SP profile system, Aliplast publishes Uf from 1.41 W/(m²·K), with the value dependent on profile combinations and infill thickness. Uf describes the profile system and should remain distinct from the Uw value for a complete window assembly. The manufacturer also lists air permeability Class 4, wind resistance Class C5/B5, and water tightness Class E1950 for the SP system. These references describe the system testing published by Aliplast, not a declaration for every finished window configuration. Within the opening design, the 14–61 mm infill range gives room for different glazing build-ups, while the frame and sash depths define the boundary around those panes. Finish choices include RAL and textured colors, wood-effect and stone-effect finishes, anodized colors, and bi-color treatments. Those options let the frame match surrounding aluminum work, pick up a material tone in the facade, or use different colors on the two sides. Pairing the finish with the bead profile and drainage treatment gives the window a coordinated appearance from the exterior and interior. Manufacturer system data and reference performance depend on the selected profiles, infill, and configuration.

Aliplast Superial: System Specifications
