DRE Otto 1

Price: $ 1,500

  • Free consultation
  • Delivery and certified installation in CT & NY
  • European quality

DRE Otto 1 Framed Glass Door

Otto 1 has a layered frame construction: the outer members are MDF, while the internal frame combines glued wood and MDF with tubular chipboard filling. A 4 mm MAT DRE pane is part of the framed interior leaf, and the edge is non-rebated. The result is a model whose material description should distinguish the visible MDF members from the internal components rather than compressing the assembly into a claim of solid wood. For the finished opening, the pane, frame surface, and door edge work together visually. Consider the glass as part of the door’s composition when matching it to adjoining rooms; the chosen version can change how much visual continuity the opening provides without changing the described core construction.

Pane and Hardware Selections

DRE lists transparent glass and a see-through dark gray alternative alongside the standard MAT DRE pane. These are different visual choices, not interchangeable descriptions of the same glass. The hinged leaf is prepared for two recessed Estetic 80 hinges, with the hinges supplied in the frame. Lock selections include magnetic options with regular-key, bathroom, cylinder, and latch-only functions. Confirm the selected function when placing the order, because appearance alone does not define how the door will close or lock. A ventilation preparation and an additional recessed hinge are listed as options. Keeping these items separate from the structural material description makes the specification clearer: pane, lock, ventilation, and frame fittings are choices attached to the base door design.

Sliding and Paired Configurations

Otto 1 can also be specified as a sliding leaf or in a two-leaf assembly. DRE lists single-leaf width codes from 60 to 100 and paired codes from 120 to 180. A paired doorway calls for a second leaf and its meeting detail, while a sliding doorway needs the mechanism and applicable hook lock and/or pulls. These are distinct order paths, so determine the movement before the corresponding frame or hardware is chosen. The recessed hinge preparation applies to the hinged version; it should not be carried over as a description of the sliding assembly. The leaf, frame, and handle are distinct components; list the pieces required for the complete opening. Use the full configuration when comparing a complete opening, especially when the second leaf, mechanism, or optional preparations are needed. For a clear specification, list the leaf materials and pane choice separately. A line that says only “wood and glass” omits the outer MDF members, glued wood and MDF in the internal frame, and tubular chipboard filling. The transparent and dark gray see-through panes are named alternatives to MAT DRE; they do not change the stated structure of the door. This vocabulary keeps the order specific to Otto 1.

Otto 1 Specifications

SpecificationDRE Otto 1 detail
Outer frame membersMDF
Internal constructionGlued wood and MDF with tubular chipboard filling
Standard glazing4 mm MAT DRE
Other panesTransparent or see-through dark gray options listed
Edge and hingeNon-rebated; recessed Estetic 80 preparation
Width codesSingle 60–100; paired 120–180
MovementHinged, sliding, or paired configuration
