DRE Kioto 1 Supreme Interior Door
Kioto 1 brings a horizontal wood-look laminate to DRE’s Supreme designer line. The leaf has a wood-based frame and tubular chipboard filling, with a 0.8 mm laminate surface whose grain runs horizontally. The wood-look effect comes from the manufactured laminate surface. The horizontal pattern gives the face a clear direction, while the selected decor can be coordinated with other interior finishes. DRE lists standard heights of 2,043 mm and 2,300 mm, so the chosen opening height affects the hinge preparation as well as the frame. Choose the visible edge in the leaf color or black, then match the movement and lock arrangement to the required height.
Height, Hinge Preparation, and Movement
At 2,043 mm, the non-rebated hinged version uses Estetic 80 preparation for two recessed hinges; the 2,300 mm version uses three hinge positions. The reverse-rebate option has its own Estetic 1821 preparation. Magnetic lock functions include regular-key, bathroom, cylinder, or latch-only choices, with the listed metal finishes. Kioto 1 is also available as a sliding leaf with the SPAZIO CD system at the 2,043 mm height standard. These are distinct preparations: select the height and movement before pairing the leaf with a frame or sliding mechanism. The sliding hardware is a separate part of that configuration, not an automatic feature of the hinged leaf.
DRE offers Silent 37 dB as an optional package for a specified non-rebated hinged door with a conventional magnetic lock operated by a handle. It adds acoustic filling and an automatic drop seal; it does not describe the standard tubular-chipboard leaf or the sliding version. The package should not be transferred to a Magic Magnetic setup with Konzerva pull preparation. If this option is required, identify the qualifying hinged layout and handle-operated lock in the order. For a sliding Kioto 1, specify the SPAZIO CD arrangement at the listed height instead. Keeping those options separate prevents the finish, movement hardware, and acoustic package from being treated as one universal configuration. The laminate and composite construction should be recorded as such in the finish schedule. Select the height before finalizing the frame, since the listed 2,043 mm and 2,300 mm versions use different hinge counts and preparations.
DRE Kioto 1 Supreme Interior Door Specifications
| Specification | Published detail |
|---|---|
| Product and line | Kioto 1, DRE Supreme |
| Leaf frame and core | Wood-based frame with tubular chipboard filling |
| Surface | 0.8 mm wood-look laminate; horizontal grain |
| Standard heights | 2,043 mm and 2,300 mm |
| Non-rebated hinges | Estetic 80; two positions at 2,043 mm, three at 2,300 mm |
| Reverse-rebate | Estetic 1821 preparation |
| Sliding option | SPAZIO CD at the 2,043 mm standard |
| Silent option | 37 dB package with acoustic filling and drop seal for the specified non-rebated, handle-operated hinged layout |
| Edge and locks | Leaf-color or black edge; listed magnetic lock functions |
| Leaf scope | Frame and handle are specified separately |
