ESWindows Prestige ES-PSD5030T Impact-Rated Pivot Entry Door

Price: $ 46,200

  • Free consultation
  • Delivery and certified installation in CT & NY
  • European quality

ESWindows Prestige ES-PSD5030T Pivot LMI Entry Door

The selected product is the ES-PSD5030T Pivot Door LMI, a Prestige exterior entrance system with thermally broken aluminum framing, a 5-inch frame depth, and a multipoint lock. ESWindows lists captured-glass, structural silicone glazing, and phenolic panel finish choices; the selected infill must still match the applicable approval. Florida Product Approval FL41358-R4.1 identifies the Pivot LMI product 41358.1 under drawing AD22-07. Its approved configuration includes Large Missile Impact and conditional use in the High Velocity Hurricane Zone. Those terms describe the approved assembly and installation, not a guarantee against hurricane damage or a blanket approval for any opening. Use the Pivot identity and FL41358-R4.1 documents together when reviewing the project. Do not substitute a French-door approval or transfer its glazing details to this pivot model.

Match the Pivot Configuration to the Opening

The Florida approval table lists +95/-95 psf as an upper design-pressure value for the approved system. The dealer's selected IWA-PSD5030-01 configuration is listed at +90/-90 psf: a 50 9/16-by-80-inch pivot door with Gray Laminated glass and an AAMA2605 White finish. These are different figures with different scopes; neither makes every size, glass selection, anchor, or substrate suitable for a project. Gray Laminated is the listed dealer glass, and tempered glass is not confirmed for this base Pivot selection. Before ordering, have the supplier and project professional check the actual dimensions, glazing, threshold, anchoring, substrate, and installation against drawing AD22-07 and current approval documents. Keep changes to the infill or hardware within the approved assembly. The exact configuration and applicable local permitting still need project review, so the listed pressure should be treated as configuration-specific information rather than a universal door rating.

Check the Pivot Submittal as a Set

Use drawing AD22-07 as the reference when the opening, threshold, anchors, substrate, and infill are reviewed together. Ask the supplier to identify the approved dimensions and glass package for the actual order, and confirm fastener locations and embedment from the applicable installation documents. A Pivot selection should remain labeled ES-PSD5030T Pivot LMI throughout the quote and approval review; details from a different door arrangement do not establish what is allowed for this unit. If the requested configuration changes, have the supplier verify the revised assembly and allowable pressure before relying on the earlier listing. The installation and permitting review should follow the current approval documents and project requirements.

ES-PSD5030T Pivot LMI Specifications

SpecificationPublished detail
Manufacturer and seriesESWindows Prestige ES-PSD5030T
Selected operationPivot Door LMI; Florida product 41358.1, FL41358-R4.1, drawing AD22-07
Frame and lockThermally broken aluminum; 5-inch frame depth; multipoint lock
Approval scopeLarge Missile Impact and HVHZ use only within the approved configuration and installation
Approval table pressureUpper listed value +95/-95 psf; not universal across configurations
Selected dealer configurationIWA-PSD5030-01; 50 9/16 × 80 inches; Gray Laminated; AAMA2605 White; +90/-90 psf
Glass qualificationGray Laminated listed; tempered glass not confirmed for this Pivot SKU
